CIRCLE FLAMER II is developed with the integration of our second generation liquid flamer plateform and CIRCLE FLAMER platform, to generate bigger and higher flame throw upto 12m with 210° waving angles, With dual built-in high pressure pump, it ensures better combustion rate than existing liquid flamers on market. The waving motor of CIRCLE FLAMER II with angle block detection and memory function thus it is more easier for operator to set angle limit. It can also be powered with 18650 batteries.

Specifications:

Dimension: 610 x 330 x 330 mm
Weight: 32kg
Input and Power: 100-240VAC, 50/60 Hz, 550W
Housing Material: Aluminum
Effect Direction: 210° (±105°)
Max. Flame Height (No Wind): Nozzle H: 10-12m
Fuels: ISOPAR G, H, L, M; ISOPROPANOL
Fuel Tank Capacity: 9L
Fuel Consumption Rate:Nozzle M: 60ml/s
Interface: NEUTRIK POWERCON TRUE1 IN/OUT;Waterproof 3-pin and 5-pin XLR IN/OUT
Control: DMX, 9-60V Pyro Signal
E-stop: Yes
ARM Indicator Light: Yes
Liquid Level Sensor: Yes
Ignition: High Voltage Electron Ignition * 2
Valve: Dual
Pump: Dual
Built-in Battery Design: Yes, 18650 battery
Use in Rain: Yes
