uFlamer ®Max is the first standalone liquid flamer with flames upto to 20m. Built-in pumping system and fuel tank makes it the only plug and play big liquid flame units available on market. Equipped with auxillary igniter and triple high voltage igniters ensure successful ignition.
Dimension: 570 x 425 x 380mm
Weight: 60kg
Input and Power: 200-240VAC, 50/60 Hz, 2.5KW
Housing Material: 304 Stainless steel
Effect Direction: Vertical
Max. Flame Height (No Wind): Nozzle XXH: 20m
Fuels: ISOPAR G, H, L, M; ISOPROPANOL
Fuel Tank Capacity: 17L
Fuel Consumption Rate: Appr. 1L/s
Interface: NEUTRIK POWERCON TRUE1 IN/OUT;Waterproof 3-pin and 5-pin XLR IN/OUT
Control: DMX, 9-60V Pyro Signal
E-stop: Yes
ARM Indicator Light: Yes
Liquid Level Sensor: Yes
Ignition: High Voltage Electron Ignition * 3
Firing Duration: 0.2-0.5s
Use in Rain: Yes
The first standalone liquid flamer with flames upto to 20m Built-in pump and fuel tank, plug and play system Equipped with external fuel input quick coupler Compact size Triple high voltage igniters Flame monitoring function Multi safety configurations: cascadable power cut-off E-stop connector, ARM indicator light, safety switch etc. Durable metal tube structure
